Winters PFQ720 PFQ Pressure Gauge — 0/3,000 PSI/KPA, 4 in, Bottom

Representative Winters PFQ manufacturer catalog image; ordered configuration is defined by listed specifications

Part Number #

PFQ720

Winters PFQ720 PFQ Pressure Gauge — 0/3,000 PSI/KPA, 4 in, Bottom

List Price:

$132.07

/each

Product Description

Winters PFQ720 PFQ pressure gauge.

Request a Quote — PFQ720

Stock, shipping and delivery are confirmed with your quotation. Include model and quantity.

Series	PFQ
Pressure range	0/3,000 PSI/KPA
Dial size	4 in
Connection size	1/2 in NPT
Connection position	Bottom
Wetted parts	Brass
Case	AISI 304 stainless steel
Lens	Polycarbonate
Ring	AISI 304 stainless steel, crimp-on
Socket	Brass
Movement	Brass
Pointer	Aluminum, anodized black
Accuracy	+/-1.5% of full scale
Enclosure rating	IP65
Working pressure	Maximum 75% of full scale
Warranty	5 years
Bourdon tube	Phosphor bronze
Fill liquid	Glycerin
Ambient/process temperature (filled)	-4 to 150 F (-20 to 65 C)
Welding	Silver alloy

Winters manufacturer specifications and documentation

Manufacturer series image is representative. Ordered dial size, pressure range, wetted materials and connection are defined by the specifications above.

WARNING: This product can expose you to chemicals including lead. See www.P65Warnings.ca.gov.
